OULANGE Straddle Carrier is a heavy-duty container handling vehicle designed for efficient transport, lifting, and stacking of ISO containers in ports, container terminals, and intermodal yards. The machine operates by straddling containers, enabling fast movement between quay cranes, storage yards, and trucks.
OULANGE Straddle Carrier is a heavy-duty container handling vehicle designed for efficient transport, lifting, and stacking of ISO containers in ports, container terminals, and intermodal yards. The machine operates by straddling containers, enabling fast movement between quay cranes, storage yards, and trucks.
As a professional straddle carrier supplier, we provide a one-stop service for lifting equipment. This straddle carrier is designed for reliability and high productivity, significantly improving container handling efficiency while reducing operating costs.
High Load Capacity
Capable of handling fully loaded 20ft and 40ft ISO containers.
Efficient Container Transport
Optimized for rapid container transfer between quay cranes, yard areas, and trucks.
Strong and Stable Structure
Heavy-duty steel frame ensures excellent stability during lifting and transport operations.
| Capacity | 35 Tons | 45 Tons | 120 Tons |
| Dimension | |||
| ( Lenght Width* Height) | 7100*5100*5500mm | 10000*5800*7000mm | 12000*8210*6900mm |
| Inner Width | 3100mm | 3400mm | 6500mm |
| Wheel Base | 6000mm | 6500mm | 9000mm |
| Min Ground Clearance | 300mm | 600mm | 900mm |
| Engine | Cumins/Weichai | Weichai 170KUW | Weichai (247KW) |
| Travel Pump | Hytek/linde/Danfos | Linde/Danfos | Linde/Danfos |
| Turning Radius | 7000mm | 8500mm | 15000mm |
| Gradeablity | 5-15% | 5-15% | 5-15% |
| Running Speed with load | 6-8km/h | 7-10km/h | 3-5km/h |
| Running Speed without load | 8-10km/h | 9-12km/h | 3-5km/h |
| Manipulation | Steering Wheel ( Can be romote control) | ||
| Lifting Tools | Customized oversized load spreader | ||
| Working Ambient Temperature | -20°C~ +50°C | ||
As an experienced manufacturer of container handling equipment, we provide high-quality straddle carriers designed to meet international port operation standards. Our solutions offer durability, efficiency, and long-term value for terminal operators worldwide.
We are an integrated industrial and trade enterprises. We have our own R&D team, factory and marketing department.
Our Crane can design and manufacture base on FEM, ISO EN, GB standard.
All our processes strictly adhere to ISO-9001 procedures, which include Material Traceability, ISO WPQR and welder certificate, Measuring Device Calibration, NDT for the welding, and full assembling and load testing before delivery.
We accept T/T bank transfer, Paypal.
We suggest you to recruit a crane service team in local to install the crane base on our Installation Guideline and User manual. If cannot, we can send engineer to your factory to guide you do the installation with extra charge, and the transportation, accommodation, translator shall be covered by your side also.
